Industrial Food Chemical Blending Machine Pharmaceutical Ribbon Powder Mixer

Jiangyin Brightsail Machinery Co.,Ltd.
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment

Industrial Food Chemical Blending Machine Pharmaceutical Ribbon Powder Mixer

  • 1
  • 2
  • 3

Brand Name : Brightsail

Model Number : BSR

Certification : CE ISO

Place of Origin : China

MOQ : one set

Price : Negotiable

Payment Terms : L/C, T/T, Western Union, MoneyGram

Supply Ability : 10 sets per month

Delivery Time : 30-35 days

Packaging Details : Wooden case or container

type : ribbon mixer

Application : industry of chemical,medical,foodstuff

Product Name : horizontal industrial food chemical blending machine pharmaceutical Ribbon powder mixer mixing machine

Material : SUS304,SUS 316,carbon steel

Volume : 50-20000L

Warranty : One year

Package : Wooden case or container

Speed : 17~76RPM

weight : depends

Contact Now

horizontal industrial food chemical blending machine pharmaceutical Ribbon powder mixer mixing machine

Product description:

Horizontal ribbon mixer is a kind of machine to mixing dry materials,powders and particles.When it running,the two ribbons rotated to two oppsite directions to achieve the purpose of uniform mixing.

Application:

It is widely used in the solid-solid (powder material) and solid-liquid (powder material & fluidity material) mixing in the field of chemical industry, pharmacy, foodstuff industry, etc.

Industrial Food Chemical Blending Machine Pharmaceutical Ribbon Powder Mixer

Main features:

1) Safety net: There is a safety net on the cover, so that operator cannot reach out arms into the mixer, danger can be prevented.
2) Ribbon inside the mixer: make the mixing effect better.

3) Discharge part: Pneumatic valve is adopted to discharge material. Mixing dry powder or powder with a little liquid are applicable.

Technical data:

Model Max work volume(L) Speed(rpm) Motor(kw) Overall size(L*W*H)(mm) Weight(kg)
BSR-100 60L 62 3 1080*758*615 330
BSR-300 180L 49 5.5 1550*812*1015 780
BSR-500 300L 46 7.5 1975*1059*1120 955
BSR-1000 600L 35 11 2340*1380*1455 1400
BSR-2000 1200L 33 15 2480*1651*1805 2500
BSR-3000 1800L 33 18.5 2945*1896*1980 3300
BSR-4000 2400L 29 22 3038*1946*2205 3600
BSR-5000 3000L 29 30 3932*2010*2035 4320
BSR-6000 3600L 26 37 3938*1882*2246 5300
BSR-8000 4800L 26 45 3986*2160*2516 6800
BSR-10000 6000L 19 55 4500*2270*2667 8900
BSR-15000 9000L 17 75 5363*2470*3020 9950
BSR-20000 12000L 17 90 5670*2650*3497 11140

The working principle of mixer:

The outer ribbon push the material from the two ends to the centre, inner ribbon push the material from center to the two ends.Thus to achieve material convention.The discharging port is set in the bottom centre, with the help of the outer ribbon, the material can be discharged completely.

Industrial Food Chemical Blending Machine Pharmaceutical Ribbon Powder Mixer

Export record:

In the past few years, we have sold machines to over 70 countries. Followed are part of the mixer export pictures

for your reference.

Industrial Food Chemical Blending Machine Pharmaceutical Ribbon Powder Mixer

Please contact us if you have interests in our products.
our email: info@brightsail-asia.com
website:www.brsmill.com
Whatsapp: +8615961653782
